IRONBARK® Stockyard Reinforcing Mesh Range

Overview

IRONBARK® Stockyard Reinforcing Range

IRONBARK® Stockyard Reinforcing Mesh Range supplied by InfraBuild Reinforcing are a range of steel reinforcing mesh products specifically developed for rural applications including stockyards, farm gates, rural gates, infill panels, rolls of wire and accessories.

IRONBARK® Stockyard Reinforcing Mesh Sheets are stocked in galvanized and black and are available in 6 x 0.9m, 6 x 1.1m, 6 x 1.2m and 6 x 1.4m sheets.

IRONBARK® Stockyard Mesh Rolls are a versatile reinforcing mesh available in the following sizes: 30 x 0.9m, 30 x 1.1m and 60 x 1.5m.

IRONBARK® Farm Gate Infills supplied by InfraBuild Reinforcing are available in 1.1m heights and in a range of lengths from 2.35–4.65m.

Typical Uses

  • Stockyards
  • Farm gates and rural gates
  • Farm fencing
  • Infill panels

Features

  • Galvanized
  • 100% fire-proof and rot-proof

To find out more about the range of galvanized and black stockyard reinforcing mesh sheets stocked at your local InfraBuild Reinforcing please contact your nearest bar shop.

Specifications
IRONBARK® Stockyard Mesh Sheet Large Galvanized
Product Code Horizontal Spacing (mm) Vertical Spacing (mm) Wire Dia. (mm) Mass (kg) Dimensions (m)
STG8812 100 150 8 47 6 x 1.2
STG8814 100 200 8 51 6 x 1.4
IRONBARK® Stockyard Mesh Sheet Galvanized
Product Code Horizontal Spacing (mm) Vertical Spacing (mm) Wire Dia. (mm) Mass (kg) Dimensions (m)
STG5109 100 250 5 13 6 x 0.9
STG51011 100 250 5 15 6 x 1.1
STG569 100 150 5 15 6 x 0.9
STG5611 100 150 5 18 6 x 1.1
IRONBARK® Stockyard Mesh Sheet Black
Product Code Horizontal Spacing (mm) Vertical Spacing (mm) Wire Dia. (mm) Mass (kg) Dimensions (m)
STB569 100 150 5 15 6 x 0.9
STB5611 100 150 5 18 6 x 1.1
STB8812 100 150 8 46 6 x 1.2
STB8814 100 200 8 51 6 x 1.4
IRONBARK® Farm Gate Infill – Galvanized
Product Code Horizontal Spacing (mm) Vertical Spacing (mm) Wire Dia. (mm) Mass (kg) Dimensions (m)
FGI8 100 196 5 7 2.35 x 1.1
FGI10 100 196 5 8 2.95 x 1.1
FGI12 100 197 5 10 3.55 x 1.1
FGI14 100 197 5 11 4.15 x 1.1
FGI16 100 198 5 13 4.65 x 1.1
IRONBARK® Stockyard Mesh Roll Galvanized
Product Code Horizontal Spacing (mm) Vertical Spacing (mm) Wire Dia. (mm) Mass (kg) Dimensions (m)
STG5109R 100 250 5 63 30 x 0.9
STG51011R 100 250 5 76 30 x 1.1
STG569R 100 150 5 75 30 x 0.9
STG5611R 100 150 5 90 30 x 1.1
STG5615R 150 150 5 194 60 x 1.5
IRONBARK® Stockyard Mesh Roll Black
Product Code Horizontal Spacing (mm) Vertical Spacing (mm) Wire Dia. (mm) Mass (kg) Dimensions (m)
STB569R 100 150 5 73 30 x 0.9
STB5611R 100 150 5 88 30 x 1.1
