Dextra Unitec® Couplers – Mechanical Splices

Overview

Dextra Unitec® Couplers – Mechanical Splices

Dextra Unitec® is a shear-bolt coupling system supplied by InfraBuild Reinforcing for the connection of concrete rebars (reinforcing bars) from 12mm to 50 mm. The Dextra Unitec® system does not require any bar end preparation. The Dextra Unitec® system is a roads authority approved system.

Typical Uses

  • Dextra Unitec® is a shear-bolt coupling system for the connection of concrete reinforcement bars from 12 to 50 mm.

Features

  • The Dextra Unitec® system does not require any bar end preparation
  • Roads authority approved system

Relevant Standards

  • AS/NZS 4671:2001 Steel reinforcing materials

To find out more about the steel Dextra Unitec® Couplers stocked at your local InfraBuild Reinforcing please contact your nearest branch.

Specifications
Product Code Dimensions (mm) Mass (kg) Qty Bolts per Coupler Bolt Size Average Torque to Shear Bolts (Nm)
Suit Bar Diameter OD  Length
UNITEC12 12 48 140 1.5 6 M12 140
UNITEC16 16 48 140 1.6 6 M12 140
UNITEC20 20 59 180 2.5 8 M16 140
UNITEC24 24 62 240 2.8 6 M16 250
UNITEC28 28 76 220 6.8 6 M20 680
UNITEC32 32 83 280 8.5 8 M20 680
UNITEC36 36 89 360 12.2 10 M20 680
UNITEC40 40 95 425 15.4 12 M20 680
