Rediwall® End Caps (AFS Systems)


Rediwall® End Caps (AFS Systems)

AFS Rediwall® supplied by InfraBuild Reinforcing is a permanent PVC formwork system. Depending on the selected profile, the extruded components of the AFS Rediwall® system either simply snap or slide into place. They automatically interconnect for rapid assembly and achieve an attractive, low-maintenance wall surface.

Rediwall® requires almost no machinery-aided installation. With its high quality semi-gloss finish it requires no additional finishing for most applications. It’s suitable as a tough, low-maintenance load-bearing solution for building subterranean structures such as basements and retention tanks. It can also be utilised for overhead applications such as party walls, columns and retaining walls.

Typical uses

  • Load-bearing solution for building subterranean structures (basements, blade walls, retention tanks, carparks)
  • Overhead applications (such as party walls, columns, retaining walls)


  • High-quality, semi-gloss finish
  • Automatic interconnection
  • Offer a low-maintenance wall surface
  • Requires almost no machinery-aided installation
  • Offers savings on time and labour costs
Rediwall End Caps (AFS Systems)
Product Code Thickness (mm) Length (mm) Mass (kg)
RW110EC3000 110 3000 2.18
RW156EC3000 156 3000 2.47
RW200EC3000 200 3000 3.18
RW256EC3000 256 3000 4.36
RW110EC3600 110 3600 2.62
RW156EC3600 156 3600 2.96
RW200EC3600 200 3600 3.82
RW256EC3600 256 3600 5.23
