Quench and Tempered Steel Wear Plate

Page Menu
Overview

Quenched and Tempered Steel Wear Plate

InfraBuild Steel Centre stocks a wide range of quenched and tempered steel wear plate, which is designed specifically for high-pressure and wear-protection applications and is available in a variety of sizes and grades.

Typical Uses

  • Lining equipment
  • Transport equipment
  • Mining equipment
  • Excavator buckets
  • Bridges
  • Dump truck wear liners
  • Deflector plates
  • Earthmoving buckets

Features

  • Range of sizes
  • Variety of grades

Relevant Standards

  • AS 3597: Structural and pressure vessel steel – Quenched and tempered plate

To find out more about the range of quenched and tempered steel wear plate stocked at your local InfraBuild Steel Centre please contact your nearest branch.

Specifications
Quenched & Tempered
Thickness mm Mass kg/m Bisalloy 80 (Tensile Strength: Typical – 830 MPa) Bisalloy 400 (Tensile Strength: Typical – 1320 MPa) Bisalloy 500 (Tensile Strength: Typical – 1640 MPa)
5 39.25 1525 x 8000 2485 x 8000
6 47.10 1525 x 8000
2485 x 8000 2485 x 8000
8 62.80 2485 x 8000 2485 x 8000
10 78.50 2485 x 8000 2485 x 8000
3100 x 8000
12 94.20 2485 x 8000 2485 x 8000 2485 x 8000
16 125.60 2485 x 8000 2485 x 8000
20 157.00 2485 x 8000 2485 x 8000
25 196.25 2485 x 8000 2485 x 8000
32 251.20 2485 x 8000 2485 x 8000
40 314.00 2485 x 8000 2485 x 8000
50 392.50 2485 x 8000
60 471.00 2485 x 8000
Plate – Bisalloy Wear Steel
BISALLOY BISALLOY BISALLOY
Wear 320 steel Wear 400 steel Wear 450 steel
Thickness (mm) Mass (kg/m2) Tensile strength: Tensile strength: Tensile strength:
Typical – 1070 MPA Typical – 1320 MPA Typical – 1400 MPA
5 39.26 1525 x 8000 1526 x 8000
6 47.08 1525 x 8000 1526 x 8000 2485 x 8000
6 47.08 2485 x 8000 2485 x 8000 2485 x 8000
8 62.78 2485 x 8000 2486 x 8000 2485 x 8000
10 78.52 2485 x 8000 2485 x 8000 2485 x 8000
10 78.52 3100 x 8000 3100 x 8000 3100 x 8000
12 94.22 2485 x 8000 2485 x 8000 2485 x 8000
12 94.22 3100 x 8000 3100 x 8000 3100 x 8000
16 125.6 2485 x 8000 2485 x 8000 2485 x 8000
16 125.6 3100 x 8000 3100 x 8000 3100 x 8000
20 156.99 2485 x 8000 2485 x 8000 2485 x 8000
20 156.99 3100 x 8000 3100 x 8000 3100 x 8300
25 196.23 2485 x 8000 2485 x 8000 2485 x 8000
25 196.23 3100 x 8000 3100 x 8000 3100 x 8800
32 251.21 2485 x 8000 2485 x 8000 2485 x 8000
40 313.98 2485 x 8000 2485 x 8000 2485 x 8000
50 392.51 2485 x 8000 2485 x 8000 2485 x 8000
60 471.03 2485 x 6000 2485 x 6000 2485 x 6000
70 549.47 1900 x 6000 1900 x 6000 1900 x 6000
75 588.77 1900 x 6000 1900 x 6000 1525 x 6000
80 627.98 1900 x 6000 1900 x 6000 1525 x 6000
90 706.45 1525 x 6000 1525 x 6000 1525 x 6000
100 785.03 1525 x 6000 1525 x 6000 1525 x 6000
Plate – Bisalloy Wear Steel (cont.)
BISALLOY® Wear BISALLOY® Wear
500 steel 600 steel
Thickness (mm) Mass (kg/m2) Tensile strength: Typical – 1640 MPA Tensile strength:
8 62.78 2485 x 8000
10 78.52 2485 x 8000 2485x 8000
10 78.52 2485 x 8000 2485x 8000
12 94.22 2485 x 8000 2485x 8000
12 94.22 2486 x 8000 2485x 8000
16 125.6 2487 x 8000 2485x 8000
16 125.6 2488 x 8000 2485x 8000
20 156.99 2489 x 8000 2485x 8000
20 156.99 2490 x 8000 2485x 8000
25 196.23 2491 x 8000 2485x 8000
25 196.23 2492 x 8000 2485x 8000
32 251.21 2493 x 8000 2485x 8000
40 313.98 2494 x 8000 2485x 8000
50 392.51 2495 x 8000 2485x 6000
60 471.03 2485 x 6000
70 549.47 1900 x 6000
75 588.77 1525 x 6000
80 627.98 1525 x 6000
90 706.45 1525 x 6000
100 785.03 1525 x 6000
Processing

InfraBuild Steel Centre can provide the following processing services for this product:

  • High-definition Plasma Cutting
  • Oxy Profiling
  • Flame Cutting
  • Punching
  • Drilling
  • Tapping
  • Bevelling
  • Counter Sinking
  • Counter Boring

To find out more about the processing services offered by InfraBuild Steel Centre please contact your nearest branch.

Delivery

InfraBuild Steel Centre can provide delivery services for this product.

Please contact your nearest branch for more information.
