Galvabond – Galvanized Steel Sheet and Coil

Page Menu
Overview

Galvabond – Galvanized Steel Sheet Metal and Coil

InfraBuild Steel Centre stocks a variety of galvanized sheet metal under the name Galvabond.

Galvabond is a family of hot dip zinc-coated galvanized steel sheeting made up of:

  • Galvabond G2 steel – a hot dip zinc-coated commercial forming steel with a spangled surface
  • Galvabond G2S steel – skin passed to improve surface quality
  • Galvabond G3N – a hot dip zinc-coated deep drawing steel with a spangled surface
  • Galvabond G3NS – skin passed to improve surface quality

Typical uses

  • Tube
  • Air conditioning ducts and panels
  • Meter boxes
  • Trailers
  • Partitioning systems
  • Cable trays
  • Scaffolding planks
  • Rendering mesh
  • Feeder troughs
  • Automotive panels and components
  • Drawn appliance panels and components

Features

  • Suitable for lockseaming up to 1.6mm thick (G2)
  • Free of fluting for three months after galvanizing (G2S)
  • Guaranteed non-ageing and free from stretcher stain (G3N)

Relevant Standards

  • AS/NZS 1365: Tolerances for flat-rolled steel products
  • AS/NZS 1397: Continuous hot-dip metallic coated steel sheet and strip – Coatings of zinc and zinc alloyed with aluminium and magnesium

To find out more about the Galvabond Galvanized Sheet Metal and Coil stocked at your local InfraBuild Steel Centre please contact your nearest branch.

Specifications
Base Metal Thickness (mm) Width (mm) (kg/m2)
0.4 915 3.43
0.4 1220 3.43
0.45 915 3.82
0.5 1220 4.22
0.55 915 4.61
0.55 1200 4.61
0.55 1220 4.61
0.55 1500 4.61
0.6 1525 5
0.7 1220 5.79
0.75 915 6.18
0.75 1200 6.18
0.75 1220 6.18
0.75 1500 6.18
0.8 1525 6.57
0.9 915 7.36
0.9 1220 7.36
0.95 1200 7.75
0.95 1220 7.75
0.95 1500 7.75
1 1220 8.14
1 1525 8.14
1.1 915 8.92
1.1 1220 8.92
1.15 915 9.32
1.15 1200 9.32
1.15 1220 9.32
1.15 1500 9.32
1.2 1525 9.71
1.5 915 12.07
1.5 1220 12.07
1.5 1500 12.07
1.55 1200 12.46
1.55 1220 12.46
1.55 1500 12.46
1.6 1525 12.85
1.9 1220 15.21
1.95 1200 15.59
1.95 1220 15.59
2.4 1220 19.13
2.45 1200 19.52
2.9 1220 23.06
Processing

InfraBuild Steel Centre can provide the following processing services for this product:

  • Cut-to-size

To find out more about the processing services offered by InfraBuild Steel Centre please contact your nearest branch.

Delivery

InfraBuild Steel Centre can provide delivery services for this product.

Please contact your nearest branch for more information.
